Please help solve this problem: A supply tank requires a vaporizer to generate sufficient pressure to pump stored fluid up into a vehicle or tank. The available head is limited as the tank level falls and it is important to minimize the system pressure drop to maintain the desired flow …
Category: Ask the Experts
When installing Multi Layer Insulation (MLI) blankets on VJ line joints or cryo storage tanks should they be wrapped and tied down tight or loose? These are usually pre-cut to size. Also should they have an access hole at the point of where the molecular sieve is installed to help …
I want to know that why there are different layers of ice over a pipe carrying a cryogenic fluid, each layer separated with clear marks / lines? What do these layers signify?
I was looking for suppliers of regenerator materials. Can you please provide a list of vendors for: • Lead spheres • Bronze screen discs • Rare earth materials and spheres Thank you in advance for any help you can provide.
We are implementing a system to recover helium from our Janis ST-500 continuous flow LHe cryostat. The recovery system uses standard 1/4" plastic tubing, which we connect directly to the cryostat's exhaust port. The problem with this setup is that the gas is still quite cold as it leaves the …
I am looking for some advice regarding cryogenic modeling in ANSYS FEA software. I have been trying to use the Transient Thermal module, in workbench 14.5, to model the cooling of a device in a dilution fridge. I have approximate values for the cooling power of each plate in the …
Are compensators and/or accumulators, high or low pressure, used in cryogenics? Are they used in space?
I would like to measure vibrations in small LHe cryostats. Could anybody recommend commercial sensors which would be suitable for the purpose? I am interested in the frequency range between 1Hz and a couple of KHz, with particular attention to the low frequency side.
In order to perform an indicative cost assessment of our helium cryogenic plant (still in the design phase), I need an estimation of the cost of carbon steel room temperature pure helium storage tanks. The storage pressure is 20 bar. Can anyone give me suggestions about how to estimate the …
In an actual experiment we would like to measure the static pressure in a cryostat in the range between one and four bar. Therefore we are looking for some (more or less) cheap pressure sensors that work in liquid helium in the pressure range up to five bar. Unfortunately all …
Can you suggest some reference textbooks for practical thermodynamics applications in cryogenic fields? I need textbooks with cryogenics calculations and examples, dimensioning procedures, second principle applications in cryogenics, heat load calculations, cryogenic pump application, etc. Do such books exist? Does any similar source of information exist?
A recent project highlighted to me that closed cycle cryogenic cooling systems use far more electrical power to reduce temperatures by a few watts than regular refrigerators. I am sure it must be something to do with the extra difficulty of removing the heat from the liquid nitrogen or similar …
I was wondering what kind of redundancy strategies are people using for their mechanical -80C freezers? I am aware of the following. Please add if you are doing something different. 1) 1 Backup freezer for every 10 freezers - Empty and maintained at -80C at all times 2) Backup C02 …
I am looking for any safety guidelines for handling cryogenic vessels of nitrogen indoors and outdoors. I am especially interested in recommendations for area monitors to detect leaks, flow detection devices, etc.
Does anyone know of a method with which to reliably move components in a cryogenic environment? We are interested in moving detectors in a cryogenically cooled (2K) vacuum chamber, which is contained within a larger cryostat/isolation vacuum with thermal shields. As the desired horizontal or vertical displacement is between 10 …
I am currently working on the design of a focal plane assembly to be implemented on a small satellite (4 EMCCD detectors) to be operated at -80°C (which is not really cryogenic and likely still considered boiling hot for most of you :-). As it is passively cooled, the assembly …
I have a question concerning the 3D drawings of a cryogenic plant. The integration of the 3D drawings of a plant with the 3D main model of a new laboratory or a new facility can be a complex work that takes a lot of time. I would like to know …
I have been looking for a source of LOX impact testing to ASTM D2512. I am aware of NASA and White Sands, but am looking for a commercial entity doing the work. No luck so far, even calling a lot of the folks on the CSA website. Any referrals will …
